Double Clamp Stainless Steel Pipe Fittings

Double Clamp Stainless Steel Pipe Fittings

DN15~DN100
Customization: Available
Application scenarios: hotels, hospitals, schools, water companies, community secondary water supply, water companies, personal home improvement.

Consult

Features Technical Indicators Overall Dimension

Advantages:
1. Ultra-long service life
2. High strength and pressure resistance
3. Strong corrosion resistance
4. Earthquake and impact resistance
5. High temperature and low temperature resistance
6. Low overall cost
7. High installation efficiency
8. Low maintenance cost
9. Fast flow rate and low resistance
10. Adapt to a variety of scenarios.
Advantages of our company compared to others:
1. Direct sales by the manufacturer, no middlemen to make a profit, and give benefits to users
2. Fully automated production line, complete process flow, national standard quality, complete qualifications
3. 5 major operation centers across the country, sufficient inventory supply. Spot goods are sent in seconds, without delaying the delivery and arrival cycle of the project
4. Free tools
5. Online and offline synchronous technical guidance
6. After-sales 24-hour customer service hotline, 1 to 1 dedicated service
7. One-stop procurement, saving customers' time
8. Multiple connection methods and customized parts to meet various customer needs
9. Long-term cooperative relations with 8000+ customers
10. One-piece delivery service, high cost performance, customers can enjoy fast and convenient service.

Stainless steel pipe
Nominal Diameter	I Series		ll Series		EN Series		Covering layer PE thickness	Insulation thickness
Nominal Diameter	Outer Diameter	Wall Thickness	Outer Diameter	Wall Thickness	Outer Diameter	Wall Thickness	Covering layer PE thickness	Insulation thickness
10	12.7	0.6	-	-	15	0.8	≥0.8	≥2.2
15	16	0.8	16(15.9)	0.8	18	1.0	≥0.8	≥2.2
20	20	1.0	22.2	1.0	22	1.2	≥0.8	≥3.0
25	25.4	1.0	28.6	1.0	28	1.2	≥0.8	≥3.0
32	32	1.2	34	1.2	35	1.5	≥1.0	≥3.0
40	40	1.2	42.7	1.2	42	1.5	≥1.0	≥3.0
50	50.8	1.2	48.6	1.2	54	1.5	≥1.0	≥3.5
60	63.5	1.5	60.3	1.5	-	-	≥1.0	-
65	76.1	2.0	-	-	-	-	≥1.2	-
80	88.9	2.0	-	-	-	-	≥1.2	-
100	101.6	2.0	108	2.0	108	2.0	≥1.2	-
125	133	2.5	-	-	-	-	-	-
150	159	2.5	-	-	-	-	-	-
200	219	3.0	-	-	-	-	-	-
250	273	4.0	-	-	-	-	-	-
300	325	4.0	-	-	-	-	-	-
